English
 |
LN-1550418
LEENOL
| Dimension (cm) : | |
|---|---|
| Weight（Kg）: | |
| Thickness (mm): | |
| Quantity: | |
Bestselling anti-fatigue mat with ergonomic benefit derived from 18 mm thick worker platform
comprised of a long-wearing top surface laminated onto a resilient microcellular vinyl base for
maximum durability, comfort, and insulation from hard floors and vibrations. Diamond plate
pattern provides traction while allowing easy twist turns.
The design and material composition make this the most versatile matting solution for
fatigue relief in both static and dynamic working positions. Slip resistance R10 according
to DIN51130 and BG-rule BGR181. Tested and certified by the National Floor Safety Institute (NFSI).
Featured with RedStop™ slip-resistant backing to prevent mats from shifting.
Available yellow borders along sides comply with OSHA code 1910-144.
Bevelled edges on all four sides to minimize risk of tripping. UniFusion™ technology
engineered to resist in the harshest work environments.
| Specification | |
| Material | 3 layers structure, surface is high strength PVC, middle layer is EPDM foam, bottom layer is conductive rubber |
| Size | 610x910x18mm, 610x450x18mm, other size can be customized |
| Max .length | 15m Max. Width:0.4-1.2m Thickness: 9-40mm |
| Color | Black or Black & Yellow |
| Surface resistance | 10e8-10e9 Ω (PVC Surface) |
| General Description | |
| Environment | Dry Areas |
| Group | Ergonomic, Anti-fatigue & Safety Matting |
| Special Characteristics | Coefficient of friction NSFI certified|Free of DOP, free of DMF, free of ozone depleting substances, free of silicone and free of heavy metals |
| Recommended Use | In manufacturing plants, assembly lines, picking, packing and logistics warehouses, individual workstations. Also suitable for commercial environments including hotels, reception desks, shop counters, department stores, banks, restaurants, etc. |
| Special Remarks | Diamond surface provides non-directional slip resistance. |
| Surface | Industrial Diamond Plate |
| Edges | Bevelled edges on all sides |
| Usage Intensity | Heavy duty |
| Installation and Use | |
| Custom Description | This mat can be ordered in custom lengths per linear meter. The mat will be produced to any specified size by the manufacturer with bevelled and sealed edges to prevent tripping. Available in grey, black, and black / yellow. |
| Cleaning Tip | Sweep regularly or dry mop the surface and the back of the mat. The surface can be damp-mopped with a mild soap/detergent. |
| Cleaning Remark | Sweep top surface daily. Damp-mop top surface periodically. |
| Technical Specification | |
| Material Specifications | PVC on microcellular vinyl base |
| Backing | Microcellular vinyl with Red Stop® slip-resistant backing |
| Process | Lamination |
| Weight kg/m2 | 5.5 |
| Rating | |
| Anti-Fatigue Rating | Best |
| Slip Resistance Rating | Best |
| Wear Resistance Rating | Best |
- 14 mm thick worker platform comprised of a long wearing top surface laminated onto a resilient microcellular vinyl base for maximum durability and fatigue relief.
- Diamond plate pattern provides traction while allowing easy twist turns.
- Slip resistance R10 according to DIN51130 and BG-rule BGR181. Tested and certified by the National Floor Safety Institute (NFSI).
- Reach compliant (Registration, Evaluation, Authorization and Restriction of Chemicals).
*The surface is made of high-strength wear-resistant PVC layer and steel pattern design.
*The foam layer and wear-resistant layer are made of special, glue hot-melt compound,
no peculiar smell and environmental protection.
*The bottom is an ergonomically designed PVC foam structure, which is flexible, wear-resistant,
and has good resilience. It can be used as a floor mat alone with a comfortable foot feel.
*Slope design, anti-kick, prevent tripping, yellow edges on both sides can be used as a warning safety function,
the warning yellow edges on both sides not only have a warning function, but also have a wear-resistant and anti-skid function.
